Wide Flat Steel Bar
Hot rolled wide flat steel bars per DIN 59200 standard, from 160x20mm to 500x80mm.
Technical Specifications
Key Features
- Wide and flat surface area
- Flatness suitable for mold making
- High surface quality
- Suitable for welding and machining
- Available in structural and engineering steels
- Large cross-section sizes
Applications
- Mold base and plates
- Heavy machine manufacturing
- Press and machine tool bodies
- Steel construction
- Shipbuilding
- Bridge and infrastructure projects
Dimension Table
| Form | Size Range | Standard | Steel Grades |
|---|---|---|---|
| Wide Flat | 160x20 - 200x30 mm | DIN 59200 | S355J2, C45, S235JR, 42CrMo4 |
| Wide Flat | 200x30 - 300x40 mm | DIN 59200 | S355J2, C45, 42CrMo4, S355J2G3 |
| Wide Flat | 300x40 - 400x60 mm | DIN 59200 | S355J2, C45, 42CrMo4, 34CrNiMo6 |
| Wide Flat | 400x60 - 500x80 mm | DIN 59200 | S355J2, C45, 42CrMo4, S355J2G3 |
Technical Notes
- 01DIN 59200 wide flats have different tolerances than EN 10058 flat bars.
- 02Width tolerance produced per +/- standard values.
- 03Flatness and wave tolerances controlled per DIN 59200.
- 04Heat-treated delivery preferred for large cross-sections.
Wide Flat Steel Bar: grades, standards and selection notes
This page covers Wide Flat Steel Bar, part of our Hot Rolled Bars range. Size range: 160x20 - 500x80 mm. Grades named for this type: S355J2, C45, S235JR, 42CrMo4, S355J2G3, 34CrNiMo6. It is supplied to DIN 59200 (hot-rolled wide flats).
Reference grades with the chemical composition (wt %) and strength values of the standard: S355J2 (W.-Nr. 1.0577 · ASTM ≈ A572 Gr.50 · JIS ≈ SM490B / SM490YB): C ≤ 0.20, Rm 470–630 MPa, Rp0.2 ≥ 355 MPa (+N, d ≤ 16 mm). C45 (W.-Nr. 1.0503 · AISI/SAE 1045 · JIS S45C): C 0.42–0.50, Mn 0.50–0.80, Rm 700–850 MPa, Rp0.2 ≥ 490 MPa (+QT, d ≤ 16 mm). The full tables and equivalents are on our grade datasheets. The table splits 160x20 to 500x80 mm into 4 size bands: the smallest band lists S355J2, C45, S235JR, 42CrMo4, the largest S355J2, C45, 42CrMo4, S355J2G3; S355J2, C45 and 42CrMo4 appear in every band.
How the other types differ, according to their data: Round Steel Bar: size range 12 - 340 mm; 42CrMo4: C 0.38–0.45, Cr 0.90–1.20, Mo 0.15–0.30 (S355J2: C ≤ 0.20, Cr —, Mo —). Hexagon Steel Bar: size range 15.5 - 100 mm (AF); C45: C 0.42–0.50 (S355J2: C ≤ 0.20). Square Steel Bar: size range 10x10 - 250x250 mm; C45: C 0.42–0.50 (S355J2: C ≤ 0.20). Flat Steel Bar: size range 10x3 - 150x60 mm; C45: C 0.42–0.50 (S355J2: C ≤ 0.20). Wire Rod (Coil): size range 4 - 36 mm; C45: C 0.42–0.50 (S355J2: C ≤ 0.20). Each shape has its own dimensional standard (Wide Flat: DIN 59200, Round: EN 10060, Hexagon: EN 10061, Square: EN 10059, Flat: EN 10058, EN 10092 and Wire Rod: EN 10017), so shape and standard are named together in an enquiry.
To request a quotation for Wide Flat Steel Bar, state the grade (for example S355J2), size, tolerance class, the standard (DIN 59200), length and quantity. Material is supplied with an EN 10204 3.1 inspection certificate; third-party inspection by bodies such as SGS, Bureau Veritas or TÜV is arranged on request. Whether the size can be supplied from stock, the minimum quantity and the lead time are stated in the quotation, which is sent within 24 hours.
Grade datasheets
Chemistry, mechanical properties and equivalents of the steel grades used for this product:
Grade comparisons
What is a hot rolled steel bar?
A hot rolled bar is produced by shaping steel between rolls above its recrystallization temperature (~1100–1250°C), in round, square, hexagonal or flat sections.
