Branch Connections / LAT

Latrolet - Lateral Outlet

Lateral outlet connecting the main at 45°, providing reduced pressure losses.

Latrolet - Lateral Outlet

Technical Specifications

Pressure
150# - 900#
Temperature
-29°C to +400°C
Size Range
4" - 36"
Materials
A234 WPB, A860 WPHY, 304/L, 316/L
Standards
ASME B16.9, MSS SP-97, EN 10253

Key Features

  • 45° main connection
  • Low pressure drop
  • Hydrodynamic profile
  • High efficiency
  • Large bore compatibility
  • Energy saving

Applications

  • Large mains
  • Low ΔP systems
  • Power generation
  • Water distribution
  • Main process lines
  • High-flow networks

Design Features

  • 45° to main
  • Low turbulence
  • Reinforced body
  • Large diameter friendly
  • Weld bevel prep
  • Field-install friendly

Connection Performance

Pressure Rating
900#
Temperature Range
-29°C to +400°C
Branch Sizes
4" - 36"
Reinforcement
Full

Dimensions follow the standard or drawing specified in the order — sent with the quote.

Technical Notes

  • 01Alternative to 90° branches.
  • 0230–50% less ΔP than 90°.
  • 03Preferred on larger lines.
  • 04Improves energy efficiency.

Latrolet: 45° lateral branch outlet

A latrolet is an integrally reinforced branch outlet whose bore leaves the run pipe at 45° instead of 90°. The base is shaped to the run pipe and joined with a full-penetration weld, while the outlet end is butt-weld, socket-weld or threaded. The angled entry keeps the branch flow aligned with the main flow, which reduces turbulence at the junction compared with a square branch. Typical uses are lateral connections on drain and relief headers, lines carrying solids or slurry, and angled insertion of thermowells and probes, where a 45° entry gives a longer immersion length in small run pipes.

The general requirements for integrally reinforced branch outlets are set out in MSS SP-97; socket and thread details follow ASME B16.11 and ASME B1.20.1 (NPT), and the butt-weld bevel follows ASME B16.25. Butt-weld latrolets are matched to the branch wall (STD, XS or Sch 160), while socket-weld and threaded versions are made in Class 3000 and 6000. Common materials are ASTM A105 and A350 LF2 for carbon steel, A182 F304L/F316L for stainless and A182 F11/F22 for Cr-Mo service.

Because the outlet sits on the run at an angle, its overall length is greater than that of a weldolet of the same size, and dimensions differ between manufacturers; check the drawing against the available space and the flow direction before ordering. Specify run size × branch size, the 45° angle, end type, wall or class and material. For a branch on a bend use the elbolet; for a square branch, the weldolet or sockolet.

What are branch connection (olet) fittings?

Olet-type branch connection fittings are forged components that create a reinforced branch outlet from a run pipe without using a tee.

Branch Outlets (Olets): guide and FAQ
