Straight Tee
Standard tee fitting designed for equal-diameter flow distribution in piping systems.
Technical Specifications
Key Features
- Equal diameter distribution
- Low flow resistance
- Easy installation
- Standard dimensions
- High pressure strength
- Welding compatibility
Applications
- Main line branching
- System integration
- Valve connections
- Instrumentation
- Sampling lines
- General piping
Dimension Table
| Size | Outside Diameter (mm) | Thickness (mm) | Center to End C, run (mm) | Center to End M, outlet (mm) |
|---|---|---|---|---|
| 1/2" | 21.3 | 2.77 | 25 | 25 |
| 1" | 33.4 | 3.38 | 38 | 38 |
| 2" | 60.3 | 3.91 | 64 | 64 |
| 4" | 114.3 | 6.02 | 105 | 105 |
| 6" | 168.3 | 7.11 | 143 | 143 |
| 8" | 219.1 | 8.18 | 178 | 178 |
| 12" | 323.9 | 10.31 | 254 | 254 |
| 16" | 406.4 | 12.70 | 305 | 305 |
Technical Notes
- 01Complies with ASME B16.9 standard dimensions
- 02Ready for butt-weld connections
- 03Suitable for radiographic and ultrasonic testing
- 04Fully traceable certified production
Other Types
Straight Tee: grades, standards and selection notes
Straight Tee belongs to our Tee Fittings range and is listed for sizes 1/2" – 36". Materials: A234 WPB, WPBW (ASTM A234 carbon steel; the W suffix marks welded construction); WP5, WP9, WP11, WP22 (Cr-Mo alloy steels for high-temperature service); 304/L, 316/L (austenitic stainless steel; L grades are low-carbon for welding, 316 adds molybdenum for chloride resistance).
All three ends have the same nominal size, and ASME B16.9 gives a single centre-to-end dimension for both run and branch. It is supplied to ASME B16.9 (factory-made wrought butt-welding fittings (NPS 1/2 to 48)), MSS SP-43 (light-wall butt-welding fittings for low-pressure, corrosion-resistant service), EN 10253 (European standard for butt-welding pipe fittings) and DIN 2615 (former DIN standard for butt-welding tees, now covered by EN 10253). The temperature range given, −196°C to +815°C, applies depending on the material grade chosen.
The dimension table on this page lists 8 sizes from 1/2" to 16"; outside diameters run from 21.3 to 406.4 mm and the wall thickness in these rows from 2.77 to 12.70 mm. A butt-welding fitting takes the wall schedule of the pipe it is welded to, so the schedule is confirmed in the quotation.
Compared with the other types in this group: Reducing Tee — branch smaller than the run; standards ASME B16.9, MSS SP-75, EN 10253, DIN 2615.
To request a quotation for Straight Tee, give the size (for example 1/2"), the wall thickness or schedule, the material (for example A234 WPB), the standard (ASME B16.9) and the quantity. Material is supplied with an EN 10204 3.1 inspection certificate; third-party inspection by bodies such as SGS, Bureau Veritas or TÜV is arranged on request. Whether the size can be supplied from stock, the minimum quantity and the lead time are stated in the quotation, which is sent within 24 hours.
What is a pipe tee?
A pipe tee is a T-shaped butt-weld fitting used to take a 90° branch off a pipeline.
